BLACK CUBE INFOBLAD
Tekniska data:
Black Cube SE
Sensitivity for output level 775 mV/ 0 dB (with activated high gain jumper)
Gain 1 kHz
Maximum input level 1 kHz
Signal to noise ratio (RMS unweighted) MM: 3.8 mV/1 kHz; MC: 0.38 mV/1 kHz
MM: 46 dB; MC: 66 dB
MM: 45 mV; MC: 4,5 mV
MM: 71 dB; MC: 63 dB
Gain 36 dB, 46 dB, 56 dB, 66 dB
Channel separation > 85 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms
1 x custom load
1 x hardwire slot
Output impedance 47 ohms
Input capacitance 100 pF
Channel mismatch typ. 0.5 dB
Bass filter 50 Hz, 6 dB/oct.
Power consumption < 3 W
Outer dimensions W x D x H Audio section: 113 mm x 108 mm x 45 mm
PWX power supply: 93 mm x 233 mm x 45 mm
Weight Audio section incl. cable to power supply: 0.4 kg netto
PWX power supply: 1.0 kg netto
