LEHMAN PRODUKTBLAD DECADE
Tekisnka data:
Decade
Sensitivity for output level 775 mV/ 0 dB (with activated high gain switch)
Gain 1 kHz
Maximum input level 1 kHz
Signal to noise ratio (RMS unweighted) MM: 3.8 mV/1 kHz; MC: 0.38 mV/1 kHz
MM: 46 dB; MC: 66 dB
MM: 45 mV; MC: 4.5 mV
MM: 78 dB; MC: 69 dB
Gain 36 dB, 46 dB, 56 dB, 66 dB
Channel separation > 80 dB at 10 kHz
Input impedance 47 kohms, 1 kohm, 100 ohms
1 x custom load
Output impedance 5 ohms
Input capacitance 47 pF to 1,370 pF
Channel mismatch typ. max 0.5 dB
Bass filter 50 Hz, 6 dB/oct.
Power consumption app. 13 VA
Outer dimensions W x D x H Audio section: 110 mm x 280 mm x 50 mm
PWX II power supply: 110 mm x 280 mm x 50 mm
Weight Audio section: 0.87 kg
PWX II power supply: 1.56 kg
