Ortofon
kr54,990.00
Tax included

The MC 90X is a reimagining of a classic, combining precision engineering with advancements in material science and magnetism.

Building on the groundbreaking technology of the MC A90, the MC 90X features a stainless-steel structure crafted using Selective Laser Melting (SLM) technology, along with the Field Stabilizing Element, Wide Range Damping, Ortofon Replicant 100 Diamond stylus, and newly developed proprietary Ortofon rubber dampers.





Specifications

Channel balance at 1 kHz < 0.2 dB
Output voltage at 1 kHz, 5cm/sec 0.25 mV
Channel separation at 1 kHz > 28 dB
Frequency response 20 Hz - 20 kHz +/- 1 dB
Compliance, dynamic, lateral 11 μm/mN
Cantilever material Boron
Stylus type Ortofon Replicant 100
Stylus tip radius r/R 5/100 μm
Coil system Quad coils
Tracking force, recommended 2.3 grams
Internal impedance, DC resistance 4 Ω
Coil wire material Aucurum (Gold-plated 6NX OFC)
Cartridge weight 9.5 grams
Recommended load resistance > 10 Ω
