Ortofon
kr54,990.00
Tax included

The MC 90X is a reimagining of a classic, combining precision engineering with advancements in material science and magnetism.

Building on the groundbreaking technology of the MC A90, the MC 90X features a stainless-steel structure crafted using Selective Laser Melting (SLM) technology, along with the Field Stabilizing Element, Wide Range Damping, Ortofon Replicant 100 Diamond stylus, and newly developed proprietary Ortofon rubber dampers.



Specifications

  • Channel balance at 1 kHz
    < 0.2 dB
  • Output voltage at 1 kHz, 5cm/sec
    0.25 mV
  • Channel separation at 1 kHz
    > 28 dB
  • Frequency response 20 Hz - 20 kHz
    +/- 1 dB
  • Compliance, dynamic, lateral
    11 μm/mN
  • Cantilever material
    Boron
  • Stylus type
    Ortofon Replicant 100
  • Stylus tip radius
    r/R 5/100 μm
  • Coil system
    Quad coils
  • Tracking force, recommended
    2.3 grams
  • Internal impedance, DC resistance
    4 Ω
  • Coil wire material
    Aucurum (Gold-plated 6NX OFC)
  • Cartridge weight
    9.5 grams
  • Recommended load resistance
    > 10 Ω
