Specifications
Voltage gain:
30.0 dB
Power consumption without load:
approx. 240 watts
Power supply capacity:
approx. 220,000 µF
Input resistance:
balanced (XLR): 2 x 16 kΩ
unbalanced (RCA): 15 kΩ
Rated power output (THD+N = 0,1%):
> 2 x 1,600 watts on 2 Ω
> 2 x 1,500 watts on 4 Ω
> 2 x 950 watts on 8 Ω
Frequency response:
10Hz – 50 kHz +0/-0.5 dB
(at 10 watts on 4 Ω)
Damping factor:
> 500 at 1 kHz 10 W on 4 Ω
Signal to noise ratio:
-96 dBA (ref. 6.325 V)
Crosstalk:
105 dB with 1 kHz
Min. loudspeaker impedance:
2 Ω
Distortion (THD+N):
0.003 % on 4 Ω load at 1 kHz and 10 watts
Dimensions (H x W x D)
328 x 530 x 545 mm
Weight:
approx. 82 kg / 180.4 lbs
+ 22 kg / 48.5 lbs flight case
