Ortofon
kr13,490.00
Tax included

The SPU GTX E cartridge delivers the best of both worlds, blending the musicality and rich tonal character that have defined Ortofon’s SPU series for decades with the latest innovations in audio technology. Experience precise and detailed sound with the Ortofon SPU GTX E cartridge, which has been upgraded with an elliptical stylus. The elliptical stylus has a more complex shape, with a narrower front radius and a broader side radius. This design allows for a greater contact area with the groove walls, resulting in improved tracking ability and higher fidelity.





Specification

Channel balance at 1 kHz 1.5 dB
Output voltage at 1 kHz, 5cm/sec 4 mV
Channel separation at 1 kHz 20 dB
Frequency response 20 Hz - 20 kHz ±3 dB
Tracking ability at 315 Hz 60 μm
Compliance, dynamic, lateral 10 μm/mN
Coil wire material OFC
Stylus type Elliptical
Stylus tip radius r/R 8/18 μm
Tracking force, recommended 4 g
Tracking angle 20°
Internal impedance, DC resistance 610 Ω
Recommended load impedance 47 kΩ
Cartridge colour Black
Cartridge weight 38 g
Recommended load capacitance 150 – 600 pF
