Maestro Grand

At the heart of theater is the human voice. Our ears are most attuned to catch every subtle nuance of this expressive instrument.

Being the hardest working speaker in a surround system, the quality level of a center channel is of major importance to a system.

Film sound springs to life from the Maestro Grand with a naturalness and intensity to match any of the Vienna Acoustics Grand main speakers.

The 1” hand coated silk-dome tweeter incorporates a triple stack neodymium magnet assembly mounted within an integral decoupling iris-shaped mounting block to reduce any extraneous resonance. Housing the tweeter in this assemble allows the tweeter to be positioned above the mid-bass drivers, assuring exceptional dispersion characteristics, as well as open and effortless high frequency response.

The thoughtful chosen position of the tweeter allows to work in perfect harmony with the dual 6” mid-bass drivers, utilizing Vienna Acoustics’ proprietary Spider Cone technology, in order to offer unrestrained dynamics and unparalleled detail in giving voice to even the most sophisticated of theater systems.

Impedance	4 Ohms
Frequency response	38-22000 Hz
Sensitivity	91 dB
Recommended Amplifier	30 - 200 Watts
Drive Units	2 x 6” Bass/Midrange Driver, X3P Cone Spidercone Technology 1 ” Dome-Tweeter, Hand-coated VA Silk Dome
Bass System	Bass Reflex, 2 x Front Ported
Bass Function	Impulse Optimizing QB 3 (Quasi-Butterworth)
Crossover Components	MKP Capacitors 1% Tolerance Coils 0,7% tol., Exclusively Air Coils Metal Film Resistors, 1% tol., Inductance Free
Coils	0,7% tol., Midrange/Tweeter Section Air Coils, Special Powder Core for Bass Section
Crossover Function	2-way, 6 dB and 12 dB Bessel
Weight	30 Ibs / 14 kg
Dimensions (W x H x D)	inches 23,25 x 6,75 x 11,5"
	mm 590 x 172 x 291 mm
Finishes	Cherry, Premium Rosewood, Piano Black and Piano White
