Accustic Arts Power II

Specifications

Inputs:

2 x balanced high level inputs (XLR)

3 x unbalanced high level inputs (RCA/Chinch)

1 x unbalanced inputs (RCA/Chinch)

as high level input or SURROUND-BYPASS (RCA)

Headphones output:

1 x metal female jack 6.3 mm; >25 Ω

Outputs:

1 x unbalanced pre-output (RCA); 47 Ω

Signal difference left/right:

< 0.4 dB (from 0 dB to -40 dB)

Input resistance:

balanced: 2 x 50 kΩ

unbalanced: 50 kΩ

Total transformer power:

max. 550 VA (watts)

Power supply capacity:

more than 80,000 µF

Rated power output (at THD+N = 1.0 %):

2 x 345 watts on 2 Ω

2 x 320 watts on 4 Ω

2 x 205 watts on 8 Ω

Rise time / fall time:

4.6 µs with 4 Ω load

Signal to noise ratio:

-97 dBA (ref. 6.325 V) – A weighted

Distortion (THD+N):

< 0,015

Damping factor:

> 710

Power consumption:

approx. 61 watts (without load)

Dimensions (H x W x D)

145 x 482 x 440 mm / 5.7 x 19 x 17.3 inches

Weight:

approx. 23.0 kg / 50.7 lbs
