Qualiton Audio P200 Power Amplifier

Tech Specs

Stereo Mode

Rated Output Power

2 x 100 Watts @ 4 or 8 Ohms

Output Load Impedance

4 or 8 Ohms

Number of Channels

2

Frequency Response

5 Hz - 85 kHz (-3 dB, 1 Watt)

18 Hz - 60 kHz (-3 dB, 100 Watts)

Total Harmonic Distortion

< 1 % across the entire power spectrum,

from milliwatts to rated output,

spanning 20 Hz to 20 kHz.

Rated Power Bandwidth

20 Hz - 20 kHz

Signal-to-Noise Ratio

> 100 dB below rated output

20 Hz - 22 kHz bandwidth, without weighting filter

> 110 dB below rated output

with A-weighting filter

Number of Outputs

2 Unbalanced POWER OUT

Number of Inputs

1 Unbalanced STEREO IN

1 Balanced STEREO IN

Input Sensitivity

(for rated output)

0.48 Volts Unbalanced

0.48 Volts Balanced

Input Impedance

10 000 Ohms Unbalanced

40 000 Ohms Balanced

Gain

+32.4 dB @ 4 Ohms

+35.4 dB @ 8 Ohms

Bridge Mode

Rated Output Power

1 x 200 Watts @ 8 Ohms

Output Load Impedance

8 Ohms

Number of Channels

1

Frequency Response

5 Hz - 85 kHz (-3 dB, 1 Watt)

20 Hz - 55 kHz (-3 dB, 200 Watts)

Total Harmonic Distortion

< 1 % across the entire power spectrum,

from milliwatts to rated output,

spanning 20 Hz to 20 kHz.

Rated Power Bandwidth

20 Hz - 20 kHz

Signal-to-Noise Ratio

> 100 dB below rated output

20 Hz - 22 kHz bandwidth, without weighting filter

> 110 dB below rated output

with A-weighting filter

Number of Outputs

1 Unbalanced POWER OUT

Number of Inputs

1 Balanced Bridge IN

Input Sensitivity

(for rated output)

1 Volt Balanced

Input Impedance

20 000 Ohms Balanced

Gain

+32 dB @ 8 Ohms

General

Vacuum Tubes

2 x 12AX7

2 x 6922

4 x KT120 (KT150 / KT170 optionally)

Power Requirement

720 W max

Weight

26 kg

Dimensions

43 x 46 x 21 cm
